CDV-704MA + DRC 40K

FINE VIEW MONITOR

CDV-704MA



CDV-704MA

AHD Memory Video Phone



Features

  • 7 inch LED display, full touch screen
  • Allows the connection up to 4 monitors
  • Intercommunicate between monitors (Page and Call)
  • Supports 2 individual door cameras and 2 AHD CCTV cameras (1.3 MP AHD maximum resolution supported)
  • Suports 10 languages (English, Korean, Spanish, Polish, Czech,Turkish, Arabic, Chinese, French, Russian)
  • Save images and video clips (Built-in Micro SD card slot) [Note: Micro SD card not included]

Specifications

  • Power Source: AC100~240V, 50/60Hz
  • Display: 7 inch wide color LCD
  • Mount type: Wall-mounted type
  • Operation Temperature: 0º ~ 40ºC
  • Wiring:
    • Door Camera: 4 wires
    • Videophone In/Out: 4 wires
    • CCTV camera: 2 wires
  • Distance: Door camera: 50 meters (0.65Ø)
  • Consumption: Max 10W, Standby 3.4W
  • Dimension (mm): 244 (W) x 180 (H) x 18 (D)

System Application



Door Camera
DRC-40KHD

DRC-40KHD

FEATURES
  • AHD 1.3Megapixel sensor
  • Compatible with AHD video doorphone monitor CDV-704MA
  • Built-in illumination sensor
  • Both indoor and outdoor use (not waterproof)
  • Surface-mounted type
  • House call and talk
  • Door release
SPECIFICATIONS
  • Power source: 12V (from monitor)
  • Wiring: 4 wires (polarity) to a monitor / 2 wires (non polarity) to a electric door lock)
  • Video Transmission Standard: NTSC
  • Image sensor: AHD 1.3MP
  • Communication: Simultaneous
  • LED: Embedded LED (activated at night)
  • Effective Viewing Angle: Horizontal 82º, Vertical 66º
  • Angle Adjustment: Up / Down 12º
  • Operating Temperature: -10ºC ~ 40ºC
  • Minimum Illumination: 0.1LUX (within300mm)
  • Distance between door camera and monitor (TIV cable): 28 meters (Ø0.5)/ 50 meters (Ø0.65) / 70 meters (Ø0.8)
  • Dimensions(mm): 96(W) x 155(H) x 32(D)
Installation Position
